Flashing Sheet

What is flashing sheet?

Flashing is one of the types of metal sheets available in the market for sealing and sealing sandwich panels, which in addition gives a beautiful appearance to the facade of the structure. If you are not familiar with a structure like a sandwich panel, you can refer to what is a sandwich panel and learn about this type of prefabricated building material. Now, on the Asia Panel website, we have decided to produce another article on what is the flash sheet, its benefits and applications.

After installing the sandwich panels, there are seams and gaps between the installed sheets, and the flashing sheet is one of the accessories designed and produced to cover these seams and to seal the structure. Due to the fact that the installation and implementation of sandwich panels is somewhat different for each project and structure, flashings are also designed and produced in various forms.

Flashings are usually produced with a thickness of 0.4 mm and in types of aluzinc, galvanized or aluminum sheets. In addition to flushing, equipment such as gutter sheet are used to direct the water from rain and snow to the gutters and the ground surface.

Types of flashing

corner flashing

As it can be seen from the name of this flashing, in the corner of the walls and changing the direction of their length, there is a need for flashing to cover the created seam, which is usually prepared in the form of an inward or outward angle, which is called corner flashing.

Flashing facade

Façade flashing is usually made in stepped or curved form. This flashing is used to cover the roof area all around the shed and is installed on the metal foundation. The lower edge of this flashing is usually the seat of the Dampa sheet and the upper edge is placed on the panel or roof edges.

Three-stage flashing

The three-step flashing is a family of facade flashing. Mostly, the height of the slopes around the sloping roofs is close to 50 to 60 cm, which can usually be covered with three steps of 15 to 20 cm created in the facade flashing. Due to the many uses of this type of facade flashing, three-step flashing is very common.

Flashing side to and under the window

In any place where there is a need to create openings, doors and windows, panels with a free edge or cut in the facade are clear. These types of flashings are used to cover this defect around and under windows or openings. In addition, it is better to use gutter flashing to cover the top of these openings.

Flashing sealant

  This is one of the most widely used types of flashings, it is used in any seam or on top of gutter flashings to improve the visual appearance of sealant flashings. These flashings are produced and prepared in the form of strips with two chamfered or bent edges.

Ceiling June Flashing

June seam is one of the necessary forecasts to deal with differences and temperature changes in the building. In addition, it is considered by the designer to improve the behavior of the building against earthquakes. Since this seam is also created in the covering of the building. For sealing and covering it, it is used in special-shaped strip flashings, which are called June seam flashings. If these flashings are used in the roof, it is called June seam flashing.

Wall flashing June

June wall flashing is also according to the ceiling type. The difference in the appearance of these two types of flashing is not significant, but the way they are installed should be in such a way that the direction of precipitation and water movement is taken into account in order to prevent possible leaks.

Crown flashing

It is one of the most widely used types of flashing, which is used in multi-slope and double-slope roofs to cover the ridge (upper part) of the roof sandwich panel, i.e. the section where two sheets of the roof sandwich panels meet. These flashings are produced in a simple and step-by-step manner and are installed in the desired location.

Flashing under the crown

This type of flashing is always used in double and multi-slope roofs along with crown flashing and is used to cover the concave line or the lower part of the roof panels.

Flashing sheet price

The price of the flashing sheet is also changing according to the fluctuations of the market, that’s why it is recommended to get the flashing sheet from the same technical and engineering office where you got your sandwich panel. To inquire about the price of the flashing sheet, contact the experts of Asia Panel through the numbers on the site.
